CKD SOLENOID VALVE 4GA210R-06-B3

Name: CKD SOLENOID VALVE 4GA210R-06-B3
Brand: VANSTECH MACHINES
Price: 1350.0 INR
Availability: InStock

Price 1350.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CKD SOLENOID VALVE 4GA210R-06-B3 Specification

Media
Compressed air (filtered, lubricated or non-lubricated)

Power
Standard 24V DC (coil voltage)

Structure
5/2 way, single solenoid, base-mounted

Material
Aluminum body with engineering plastic and brass components

Air Consumption
Depends on application, typically minimal for pilot solenoids

Speed
High speed response, 10ms or less

Maximum Torque
Not applicable, pneumatic valve

Ambient and Fluid Temperature
-10C to +50C (no freezing)

Coil Insulation Class
Class B

Model
4GA210R-06-B3

Port Size
1/8'' (Rc1/8 or NPT1/8 depending on variant)

Response Time
10 ms or less

Manual Override
Yes, locking push-button type

Operating Pressure Range
0.2 to 0.7 MPa (2 to 7 bar)

Mounting Type
Base mounted

Electrical Entry
Grommet or DIN connector type

About CKD SOLENOID VALVE 4GA210R-06-B3

The CKD 4GA210R-06-B3 is a pilot-operated 5-port, 2-position single-solenoid pneumatic valve from the 4GA2 Series. It is designed for controlling double-acting pneumatic cylinders in industrial automation and machine control.

Key Specifications

Parameter	Specification
Manufacturer	CKD Corporation
Model	4GA210R-06-B3
Series	4GA2
Valve Type	Pilot-operated solenoid valve
Port Configuration	5-port, 2-position (5/2-way)
Solenoid	Single solenoid with spring return
Port Size	Rc 1/8 (06)
Operating Medium	Filtered compressed air
Operating Pressure	Approximately 0.2 to 0.7 MPa (pilot operated)
Proof Pressure	1.0 MPa
Ambient Temperature	5C to +50C (non-freezing)
Mounting	Body (individual) mounting
Manual Override	Yes
Protection	Dust-resistant industrial construction

Model Code Interpretation

4GA2 4GA Series pilot-operated directional control valve
10 Valve size
R Body-piped (individual valve)
06 Rc 1/8 port size
B3 24 VDC solenoid coil with connector/grommet style (configuration depends on the specific ordering code)

Features

5-port, 2-position directional control.
Fast response and long service life.
Low power consumption coil.
Manual override for maintenance and testing.
Suitable for continuous-duty industrial applications.
Compatible with CKD manifold systems.

Typical Applications

Pneumatic cylinders
Packaging machines
Assembly automation
Conveyor systems
Material handling equipment
General factory automation

Reliable and Flexible Pneumatic Control

Engineered for rapid switching and consistent performance, the 4GA210R-06-B3 makes use of quality materials like aluminum and brass. Its base-mounted configuration, coupled with high-speed response under 10ms, ensures compatibility with automation systems demanding both speed and reliability. The valve operates on standard 24V DC for straightforward integration.

Convenient Operation and Maintenance

A locking push-button manual override enables quick interventions and manual operation during setup or emergencies. With options for either grommet or DIN connector electrical entry, installation is adaptable for various system layouts. Maintenance is streamlined through durable construction and minimal pilot air consumption.

FAQ's of CKD SOLENOID VALVE 4GA210R-06-B3:

Q: How do I install the CKD 4GA210R-06-B3 solenoid valve in my pneumatic system?

A: To install the solenoid valve, mount it securely using the provided base mount and connect the appropriate port size (Rc1/8 or NPT1/8) to your piping. Select either grommet or DIN connector for electrical entry and ensure the coil is powered with 24V DC. Make sure to filter compressed air supply and comply with the specified temperature and pressure ranges.

Q: What types of compressed air are suitable for use with this valve?

A: This valve is compatible with both lubricated and non-lubricated filtered compressed air. Ensuring adequate filtration will maintain high performance and prevent internal contamination or wear.

Q: When can I use the manual override on the 4GA210R-06-B3 solenoid valve?

A: The manual override, a locking push-button, is ideal for setup, testing, or emergency operation when electrical control is unavailable. Be sure to reset the manual override after intervention to return to automatic operation.

Q: Where can the CKD solenoid valve be applied in industrial settings?

A: This valve is suitable for use in various automation environments including material handling, packaging, and process control where compact, high-speed pneumatic actuators are required.

Q: What benefits does the high-speed response time offer?

A: With a response time of 10ms or less, the valve enables fast switching and precise control, which are critical for achieving optimal cycle times and efficiency in automated processes.

Q: How does the ambient and fluid temperature range affect valve performance?

A: Operation within -10C to +50C, avoiding freezing, ensures consistent valve performance and prevents damage or malfunctions related to extreme temperatures.

Q: Is maximum torque relevant for this pneumatic solenoid valve?

A: Maximum torque does not apply, as this is a pneumatic control valve, not an actuator. Flow control and response speed are the primary performance factors.
